HydroTap G5 BA Arc Plus Chrome

Confirm Purchase

Do you own an uninstalled HydroTap?

Yes No

Confirm Purchase

Please purchase a HydroTap first

Confirm Purchase

Upon purchasing this product, our customer care team will contact you to discuss the following requirements:

Is the Zip unit onsite?
Sufficient Power Supply - 1 x 10 amp (within 1 metre of the installation location)
Water available to unit
Is stone bench cutting required?
Will your Zip unit be installed over a font or sink?
Sufficient space available in cabinetry - available in the product install guide

Confirm

Click to Zoom

Find a Retailer

Finish

Please select a finish in order to add the item to cart.

RRP ^$ 3695 ^.00 incl. GST Qty

Add to Cart

Boiling

Ambient

Filtered

H5L785Z00NZ

Zenith HydroTap Design Range Boiling, Ambient, Filtered water system features a single under bench command centre including full colour interactive touch screen display with pin code protection and customisable settings including boiling water safety mode, 3 energy saving modes including ON/OFF timers and 2 hour sleep mode, antimicrobial protection impregnated into key water paths for enhanced hygiene, and 0.2 micron water filtration.

Manufacturing Code: H5L785Z00NZ
Capacity: Residential

Have more questions?

We’re here to help. Contact us for advice or more details.

0800 558 055 Email Us Find a Retailer

Product Details

Specifications

Tap: Zenith HydroTap Design Range ARC Plus Tap (Chrome)
Water Pressure: Min 170kPa - Max 700kPa
Water Connection: 1/2" BSP (G1/2)
Water Supply Requirements: Cold
Water Valves: Integrated 500kPa Pressure limiting valve and Dual Check Valve
Power Rating: 1.35kW 220-240V 50Hz
Power Supply: 1 x 10 Amp socket outlet
Dimensions: W280mm x D313mm x H333mm
Product Approvals: WaterMark, RCM
Warranty: 5 years (appliance warranty 36 months plus additional 24 months tank warranty)

Manuals

Quick Guide
Instruction Manual
User Manual
HydroTap Clean Safety Data Sheet

Brochures

Product Brochure

Installation

Installation Requirements

1. Installation and connection of your Zenith HydroTap must be carried out by a qualified person, observing national and local regulations.2. You will require suitable mains electrical and drinking water connections, plus waste water drainage all within 1.5 metres of the product.3. HydroTap is air-cooled so discrete cabinetry cut-outs are required for ventilation.4. Installation on most bench tops is straightforward however some stone bench tops may require a specialised cutting service.5. If you live in a hard water area, we recommend installation of a Zenith scale filtration kit.6. Installation by Zenith Professional Service can be arranged with a phone call or through www.Zenithwater.com
